The comparison is usually framed as detail versus size, which is the least useful way to look at it. Both processes make good parts. They differ in what they demand from you afterwards, and that is the variable that decides whether a printer gets used or sits under a dust sheet. Pick the process that fits the room, the ventilation, and the amount of handling you are willing to do every single time a print finishes.
What each process physically does
Fused deposition modelling pushes a thermoplastic filament through a heated nozzle and draws each layer as a path of extruded material. The finished part is a stack of welded lines.
Masked stereolithography, the MSLA process used by the LCD resin printers compared on this site, exposes liquid photopolymer through an LCD mask so an entire layer cures at once. The finished part is a cross-linked polymer. Other resin printers use laser SLA or DLP, so resin and MSLA are not interchangeable names for every machine.
That difference in bonding is the root of almost everything below. Formlabs’ process comparison describes FDM as producing mechanical bonds between layers, while SLA cross-links photopolymers across layers into fully dense, isotropic parts whose strength does not depend on print orientation.
Where resin genuinely wins
Fine detail and surface finish. Formlabs characterises SLA by fine features, smooth surface finish and part precision, with minimal visible layer lines, against FDM resolution being defined by nozzle size with clearly visible layers and voids between the rounded extrusion lines. For miniatures, jewellery patterns, dental and anatomical models, and anything with sub-millimetre text or texture, this is not a close contest.
Isotropy. A resin part is roughly as strong along Z as it is along X. An FDM part has a weak axis by construction, and designing around it is a permanent tax on functional parts.
Speed on tall, detailed work. Because MSLA cures a whole layer at once, print time scales with height, not with how many objects are on the plate. A plate packed with thirty miniatures takes about as long as one. Formlabs’ own figure for a roughly 15 cm cube is around nine hours in Draft Resin at 200 micron layers against 80 to 90 hours for the FDM equivalent, though it also notes that the two become comparable when printing at similar layer heights.
Material properties you cannot extrude. Formlabs lists transparent, elastic, castable, and high-temperature formulations, including one with a 238 degrees C heat deflection temperature.
Where FDM genuinely wins
Finished part is finished. Snip the supports and the part is done. There is no solvent, no wash vessel, no UV chamber, and no glove protocol.
Large and functional parts. FDM build volumes reach up to 300 x 300 x 600 mm in Formlabs’ comparison, against up to 300 x 335 x 200 mm for standard SLA. Big brackets, enclosures and jigs are FDM’s home ground, and a large resin part is expensive in both resin and peel forces.
Material cost. Formlabs quotes standard thermoplastics around 50 dollars per kilogram, with engineering filaments at 100 to 150, against 149 to 200 dollars per litre for most standard and engineering resins. Consumer resin sells well below Formlabs’ professional pricing, but the ordering stays the same.
Room compatibility. This is the decider more often than any print-quality argument.
The part of the comparison people skip
Resin printing carries an ongoing chemical handling requirement that FDM does not. NIOSH’s guidance on safe 3D printing treats desktop printing as a source of ultrafine particles and chemical emissions, asks for a risk management plan following the hierarchy of controls, and puts engineering controls ahead of the rest: capture emissions at the machine with a ventilated enclosure or fume hood, which it describes as more efficient than diluting them with general room ventilation afterwards.
On top of the air, there is the contact hazard. Formlabs’ resin care guidance requires chemically resistant nitrile or neoprene gloves, not latex, and specifies that resin on skin is removed with soap and water and never with alcohol, hand sanitiser or any other solvent. Every print, every time.
None of this makes resin printing unreasonable. It makes it a workshop process. If the only available space is a bedroom with a window that does not open, or a shared flat where the wash station has to live next to a kettle, FDM is the correct answer regardless of what the sample photos look like.
Side by side
| Resin (MSLA) | FDM | |
|---|---|---|
| Detail and surface | Fine features, minimal visible layers | Resolution set by nozzle, visible layers |
| Layer bonding | Cross-linked, isotropic | Mechanical bonds, weak Z axis |
| Typical build volume | Up to 300 x 335 x 200 mm | Up to 300 x 300 x 600 mm |
| Time scaling | With part height, not plate quantity | With total extruded path length |
| Material cost | 149 to 200 USD per litre (Formlabs figures) | 50 USD per kg standard, 100 to 150 engineering |
| Post-processing | Wash in solvent, dry, UV post-cure | Remove or dissolve supports |
| PPE required | Nitrile or neoprene gloves, eye protection | None routinely |
| Ventilation | Engineering controls recommended | Still recommended, lower burden |
| Wear items | Release film, LCD panel, vat | Nozzles, belts, build surface |
| Best at | Miniatures, dental, jewellery, fine detail | Enclosures, brackets, large functional parts |
Running costs are not where you expect
Resin consumables are the release film, which is a wear item replaced on a schedule of prints rather than years, the LCD panel, which dims with accumulated hours and eventually underexposes everything until replaced, and the vat itself. Add solvent, gloves and filters as recurring spend.
FDM consumables are nozzles, the build surface, and belts. They are cheaper and they fail more gracefully. A worn nozzle degrades quality; a punctured release film ends the print and can flood the machine.
Neither is expensive in absolute terms. The relevant difference is that resin running costs arrive whether or not the print succeeds, because a failed resin print still consumed resin, still needs washing, and may still have left cured debris in the vat.
Deciding
Choose resin if the work is small and detailed, if surface finish is the point, if isotropic strength matters, and if you have a ventilated space and will keep to a glove and wash routine. Start with the resin starter kit list to plan the equipment beyond the printer, then calibrate exposure time on an MSLA printer before committing to a batch.
Choose FDM if the parts are large or functional, if the printer has to live in living space, or if the honest answer about post-processing discipline is that it will not happen every time. In that case the class worth buying is an enclosed CoreXY machine rather than an open bedslinger, because the enclosure is what keeps ABS and ASA from warping and contains particulate at the same time. The Bambu Lab P1S is the reference point in that class: Bambu Lab’s P1 series documentation lists a fully enclosed chamber, CoreXY kinematics with a 500 mm/s top speed and 20,000 mm/s squared acceleration, a direct-drive extruder, an all-metal hotend, automatic bed levelling, and optional multi-material printing through the AMS.
One caveat on that same page is worth reading before you buy on the enclosure argument alone. Bambu states that the P1S is not recommended for directly printing fibre-reinforced filaments such as glass fibre or carbon fibre until an extruder and hotend upgrade is done. If carbon-filled filament is the specific reason you want an enclosed machine, that upgrade is part of the price, or the X1-Carbon is the model that ships ready for it.
Compare the whole workflow and cost per usable part
Use the same model and required finish when comparing processes. Formlabs’ process comparison includes equipment, material and labour in its cost discussion. A cheap bottle or spool alone does not answer what a finished batch costs.
| Stage | FDM planning question | Resin planning question |
|---|---|---|
| Preparation | How much support material does this orientation need? | Are islands supported and hollow spaces drainable? |
| After printing | Will support removal and sanding deliver the required finish? | Is there capacity to wash, dry and post-cure the whole batch? |
| Repeat production | How much material and handling does each extra part add? | How many parts fit at the same height, and how much cleanup remains? |
Make a worksheet using your slicer’s material estimate, the actual purchase price and the number of usable parts. Include supports and failed attempts in material consumed, then record hands-on labour separately from unattended machine time. This is a budgeting method, not a fixed cost multiplier between technologies. The wash-and-cure walkthrough explains the resin finishing stages to include; the documented resin handling requirements still apply during cleanup.
When owning both makes sense
A mixed workload can justify separate processes: for a tabletop project, consider FDM for storage trays and larger terrain, with resin for detailed figures. For a prototype, compare a filament enclosure with a resin presentation model. These are examples of dividing work by purpose, not promises of a payback period. List the parts you actually plan to make, check material properties for their intended use, and buy a second machine only when that workload warrants its separate space and workflow.
